13
[PBP]: Picture by Picture
Open up a sub-window
side-by-side of another
signal source.
A
(main)
B
When the sub source is
not detected:
A
(main)
B
Note
The black strip shows on the top and
the bottom of the screen for the correct
aspect ratio when in the PBP mode. If
you expect to see full screen side by side,
adjust your devices resolutions as pop up
attention resolution, you will able to see
2 devices source screen project to this
display side by side without black strips.
Note the analog signal is not support
this full screen in PBP mode.
• PIP / PBP Input: There are three
different video input to choose as
the sub display source: [HDMI 2.0],
[DisplayPort], and [USB C].
Please refer below table for compatibil-
ity of main/sub input source.
SUB SOURCE POSSIBILITY (xl)
Inputs HDMI DisplayPort USB C
MAIN
SOURCE
(xl)
HDMI ● ● ●
DisplayPort ● ● ●
USB C ● ● ●
• PIP Size: When PIP is activated,
there are three sub-window sizes to
choose: [Small], [Middle], [Large].
B
A
(main)
Small
Middle
Large
• PIP Position: When PIP is activated,
there are four sub-window positions
to choose.
Top-Left Top-Right
B
A
(main)
B
A
(main)
Bottom-Left Bottom-Right
B
A
(main)
A
(main)
B
• Swap: The main picture source
and the sub picture source
swapped on the display.
Swap A and B source in [PIP] mode:
B
A
(main)
↔
B
(main)
A
Swap A and B source in [PBP] mode:
A
(main)
B
↔
B
(main)
A
• Off: Stop MultiView function.
A
(main)
Note
When you do the SWAP function, the
video and its audio source will swap at
the same time.
