12
PRODUCT DESCRIPTION
1.4.1 VESA Grid
Model Name VESA Grid
PD-43Q 200(W) x 200(H) mm
PD-55Q 400(W) x 400(H) mm
PD-65Q 400(W) x 400(H) mm
Caution:
To prevent the display from falling:
♦ For wall or ceiling installation, we recommend installing the
display with metal brackets which are commercially available.
For detailed installation instructions, see the guide received with
the respective bracket.
♦ To lessen the probability of injury and damage resulting from fall
of the display in case of earthquake or other natural disaster, be
sure to consult the bracket manufacturer for installation location.
Note:
♦ For PD-43Q / PD-55Q wall-
mounting kits, use M6 mounting
screws (having a length 10 mm
longer than the thickness of the
mounting bracket) and tighten
them securely.
♦ For PD-65Q wall-mounting kits,
use M8 mounting screws
(having a length 15 mm longer
than the thickness of the
mounting bracket) and tighten
them securely.
♦ Unit without base weight is
10.7 kg (PD-43Q), 16.6 kg (PD-
55Q), or 27.8 kg (PD-65Q). The
equipment and its associated
mounting means still remain
secure during the test. For use
only with UL Listed Wall Mount
Bracket with minimum weight/
load is
14.9 kg (PD-43Q),
22.7 kg (PD-55Q), or 33.6 kg
(PD-65Q).
PD-65Q
MUTE MENU INPUT
400mm
400mm
