40 Menu operation
4. Main menu: Installation
Structure
Function descriptions
Menu Options
Projector Position Front / Front Ceiling / Rear / Rear Ceiling
2D Keystone
H: -30 – +30
V: -30 – +30
Auto Vertical Keystone Off / On
Test Pattern On / Off
High Altitude Mode On / Off
Baud Rate
9600/14400/19200/38400/57600/
115200
Corner Fit 0~60
Image Resizing
Digital Zoom 1.0X – 1.8X/2.0X
Digital Shrink & Shift 0.75X~1.0X
Blanking
Modes of Adjustment
Top
Bottom
Left
Right
Reset All Blanking Settings
Image Memory
Save Image Memory Memory-1 / Memory-2 / Memory-3 /
Memory-4 / Memory-5 Apply Image Memory
Rename
Menu Descriptions
Projector
Position The projector can be installed on a ceiling or behind a screen, or with one or
more mirrors. See Choosing a location on page 11 for details.
2D Keystone See Correcting keystone on page 17 for details.
Auto Vertical
Keystone Automatically corrects the keystoning at the top/bottom side of the
projected image.
Test Pattern
Adjusts the image size and focus and
check that the projected image is free from
distortion.
