Plena Mixer Amplifier Installation | en 15
Bosch Security Systems B.V. Installation and Operation manual PLE-1MExx0-xx | V1.0 | 2011.04
5 Installation
5.1 Unpack unit
1. Remove the unit from the box, and discard the packaging material according to local
regulations.
2. Use your fingernails to carefully peel off the protective plastic film from the label holders.
Do not use sharp or pointed objects.
5.2 Check settings/connections
1. Connect any additional equipment (see Section 6.1 Connecting inputs and
Section 6.2 Connecting outputs ).
2. Check the settings (see Section 7.1 Unit settings ).
5.3 Connect unit to mains
1. Make sure the power switch on the front of the unit is set to Off.
2. Connect the power cord to the mains connector and plug it into the mains outlet.
Figure 5.1 Power connection and voltage selector
CAUTION!
Before connecting power, always check the voltage indicator plate at the rear of the unit.
