Plena Mixer Amplifier Technical Data | en 23
Bosch Security Systems B.V. Installation and Operation manual PLE-1MExx0-xx | V1.0 | 2011.04
10 Technical Data
10.1 Electrical
10.1.1 Mains power supply
10.1.2 Power consumption
10.1.3 Performance
10.1.4 Mic./Line input 4 x
Voltage PLE-1MEXX0-EU: 230 VAC, ±10%, 50/60 Hz
(reduced power at lower mains)
Voltage PLE-1MEXX0-US: 120 VAC, ±10%, 50/60 Hz
(reduced power at lower mains)
Inrush Current PLE-1ME060-EU: 5 A
Inrush Current PLE-1ME060-US: 10 A
Inrush Current PLE-1ME120-EU: 10 A
Inrush Current PLE-1ME120-US: 20 A
Inrush Current PLE-1ME240-EU: 12 A
Inrush Current PLE-1ME240-US: 24 A
PLE-1ME060-XX: 200 VA
PLE-1ME120-XX: 400 VA
PLE-1ME240-XX: 800 VA
Frequency response: Line 60 Hz to 20 kHz
(+1/-3 dB @ 10 dB ref. rated output)
Mic. 70 Hz to 20 kHz
(+1/-3 dB @ 10 dB ref. rated output)
Distortion: <1% @ rated output power, 1 kHz
Bass control: Max. -10/+10 dB
Treble control: Max. -10/+10 dB
Input 1 (Push-to-talk contact
with priority):
5-pin Euro style, balanced, phantom
Input 2: 3-pin Euro style, balanced, phantom
Input 3 & 4: TRS Jack (1/4, 6.3 mm), balanced
Sensitivity: 1 mV (mic); 300 mV (line)
Impedance: >1 kOhm (mic); >5 kOhm (line)
Dynamic range: 93 dB
S/N (flat at max. volume): >63 dB (mic); >70 dB (line)
S/N (flat at min. volume/muted): >75 dB
CMRR (mic.): >40 dB (50 Hz to 20 kHz)
Headroom: >17 dB
Speech filter: -3 dB @ 315 Hz, high-pass, 6 dB/oct
Phantom power supply 16 V via 1.2 kOhm (mic)
