English • 11 Installation Guide • ControlSpace ESP-880A/880AD/1240A/1240AD
pro.Bose.com Introduction
Available Accessories
ESP-880A, ESP-880AD, ESP-1240A and ESP-1240AD processors are compatible with Bose programmable
controllers and simplified volume/zone controls. These processors work with the following interfaces:
Model Part Number Notes
ControlSpace CC-64 control center PC 041760 Provides network control of any Bose
networkable hardware.
ControlSpace CC-16 zone controller PC 041761 Uses CC-16 port. Up to 15 devices can
be used with any Bose ESP engineered
sound processor.
ControlSpace CC-4 room controller PC 042023 Uses GPI port. Requires five control inputs
and one ground termination.
ControlSpace CC-3D control center PC 079061 (US, white)
PC 079047 (US, black)
PC 079053 (EU, white)
PC 079058 (EU, black)
PC 079041 (Japan, white)
PC 079064 (Japan, black)
Uses Ethernet port. Requires additional
Power-over-Ethernet (PoE) switch.
ControlSpace CC-2D control center PC 079063 (US, white)
PC 079043 (US, black)
PC 079071 (EU, white)
PC 079049 (EU, black)
PC 079066 (Japan, white)
PC 079046 (Japan, black)
Uses Ethernet port. Requires additional
Power-over-Ethernet (PoE) switch.
ControlSpace CC-1D control center PC 079059 (US, white)
PC 079051 (US, black)
PC 079042 (EU, white)
PC 079070 (EU, black)
PC 079062 (Japan, white)
PC 079060 (Japan, black)
Uses Ethernet port. Requires additional
Power-over-Ethernet (PoE) switch.
Volume Control with A/B switch
user interface
PC 041967 Uses GPI port. Requires two control inputs
and one ground termination.
Volume Control user interface PC 041966 Uses GPI port. Requires one control input
and one ground termination.
