50 User's Guide Fireface UCX II © RME
23. Operation and Usage
23.1 General
Using the rotary encoder, the four buttons and the clear colour display the Fireface UCX II can
be configured and set up completely at the device. Additionally internal memory allows for the
permanent storage of six different states of the unit. Therefore the Fireface UCX II is able to
operate fully stand-alone, without any connected computer. In stand-alone operation it can trans-
form into totally different devices by the simple click of a button. Furthermore TotalMix FX, and
with this the application examples shown below, can also be controlled via MIDI, see chapter
28.6,
Stand-Alone MIDI Control .
23.2 Settings at the Unit
The Fireface UCX II has a simple menu structure, depending on the button pressed.
MIC/GAIN. First push brings up the Mic.Gain 1/2 , second push Line/Instr. Gain 3/4 , third push
returns to the meter screen.
REC/PLAY. Brings up the Record/Playback (Direct USB Recording) menu, second Rec/Play
Settings , third push returns to the meter screen.
CHAN/MIX. First push brings up the Channel menu, second push the Mix to menu, third push
returns to the meter screen.
The
Mix to menu gives access to the whole submix functionality, mix destination and source. A
source can be modified in mix level and panorama.
SETUP/REV. First push brings up the Options menu with access to the subpages Clock,
Load/Store all Settings, Hardware/Diagnosis and Control Room. Second push brings up Re-
verb/Echo with the subpages Reverb and Echo .
23.3 Store / Load Setups at the Unit
After hitting the key SETUP/REV, the encoder gives access to the subpage Load/Store all Set-
tings. First select the preferred memory slot, then the desired process (load or store). The
load/store process is completed by pushing the encoder for more than one second.
The UCX II has six memory slots for free usage. Three fixed slots offer convenient and quick
reset and configuration of the unit:
Factory. Sets the unit into factory default state.
AD/DA. Configures an ADAT analog to digital and vice versa converter (8 analog I/Os).
Clear Mix. Performs a Total Reset of TotalMix FX.
23.4 Storing Setups from the Computer
Setups can be loaded into the unit from the computer. As the Setups are usually generated at
the computer the final step of transmission offers a convenient workflow. In TotalMix FX use
Options / Store current state into device to select the desired storage place (Setup) within the
unit.
