1-20 Chapter 1: Product Introduction
Chapter 1
16. FlexKey button (Reset)
Press the FlexKey button to reboot the system. You may also configure the button and
assign a quick access feature such as activating Safe Boot or turning Aura lighting on
or off to the button.
This button set to [Reset] by default. You can assign a different function to this button in
the BIOS settings.
15. CPU Over Voltage jumper
The CPU Over Voltage jumper allows you to set a higher CPU voltage for a flexible
overclocking system (depending on the type of the installed CPU). Set to pins 2-3 to
increase the CPU voltage setting, or set to pins 1-2 to use the default CPU voltage
setting.
