ROG MAXIMUS Z790 HERO 2-5
Chapter 2
To install an AIO cooler
• We recommend using a LGA1700 compatible cooling system when installing a
cooling system to an Intel ® 700 series motherboard.
• Additional holes for LGA1200 compatible cooling systems are also available on
ASUS’ Intel ® 700 series motherboards, however, we still strongly advise consulting
with your cooling system vendor or manufacturer on the compatibility and
functionality of the cooling system.
• If you wish to install an AIO cooler, we recommend installing the AIO cooler after
installing the motherboard into the chassis.
AIO_PUMP
W_PUMP+/
CPU_OPT
CPU_FAN
