LCD CONTROL PANEL LOCKOUT
When
AutoLock
menu is set to
ON
, the LCD display backlight will turn OFF after 30
seconds and the Control Panel will lock and the display will show
LOCKED*****
.
Press and hold the
MODE
button for 5 seconds to unlock.
When
AutoLock
menu is set to
ON1
, the LCD display backlight will turn OFF after 30
seconds and the Control Panel will lock and the display will show
LOCKED*****
.
To unlock the Control Panel follow these steps:
1.
When locked, the display will show:
LOCKED*****
2.
Press
UP
, then the display will change to:
LOCKED****
(one * disappears)
3.
Press
DOWN
, then the display will change to:
LOCKED***
(two * disappear)
4.
Press
UP
, then the display will change to:
LOCKED**
(three * disappear)
5.
Press
DOWN
, then the display will change to:
LOCKED*
(4 * disappear)
6.
Press
ENTER
, then the display will change to
LOCKED
and then become unlocked.
ELATION© SIXBAR 1000 IP™
S Y S T E M M E N U
Specifications are subject to change without any prior written notice.
MENU
OPTIONS / VALUES (Default Settings BOLD)
DESCRIPTION
DMX MODE
ADDR:xxx
CH:xx
ADDR:
001
- 512
CH:
06
, 07, 11, 13, 36, 72, 75, 79
Set DMX Address.
Set DMX Channel Mode.
SECONDRY
M O D E
Secondry
Set unit to Secondary Mode.
AUTO RUN
FQN:xx
FQN:
0
1-99
Set the number of times each internal macro will
repeat before moving to the next macro.
01.STATIC
-
15.FLOW1
01
-15
Select Internal Program Macro.
See
PROGRAM MACRO MENU
for more details.
DimCurve
Standard
, Stage, TV, Architec, Theatre
Set desired Dimming Curve.
Flip
ON,
OFF
Set starting LED.
See FLIP Section for more details.
NO DMX
Hold
, Blackout, Program
Define how fixture reacts when NO DMX signal
present.
Manual
R
000
-255 G
000
-255 B
000
-255 W
000
-255
A
000
-255 U
000
-255 STR:
00
-99
Set RGBWAU and Strobe Values manually.
Macros
00
-63
Select Internal Color Macro.
See
COLOR MACRO MENU
for more details.
AutoLock
OFF (default)
, ON, ON1
Set LCD Control Panel Lockout Function.
Temp.
000
Fixture Internal Temperature (Celsius).
