ELATION© SIXBAR 1000 IP™
DMX Channel Values / Functions Version 1 (79 DMX Channels)
Features are subject to change without any prior written notice.
*Control of LEDs depends on the Pixel Flip setting.
DMX CHANNEL MODE
VALUE FUNCTION
6CH 7CH 11CH 13CH 36CH 72CH 75CH 79CH
67 67 67
RED LED - LED [12]
0-255 Red (0-Black - 255-100%)
68 68 68
GREEN LED - LED [12]
0-255 Green (0-Black - 255-100%)
69 69 69
BLUE LED - LED [12]
0-255 Blue (0-Black - 255-100%)
70 70 70
WHITE LED - LED [12]
0-255 White (0-Black - 255-100%)
71 71 71
AMBER LED - LED [12]
0-255 Amber (0-Black - 255-100%)
72 72 72
UV LED - LED [12]
0-255
UV (0-Black - 255-100%)
7 7 7 73 73
MASTER DIMMER
0-255 0 to 100%
8 8 74 74
STROBE
0-31 NO Function
32-63 LEDs ON
64-95 Strobe Effect SLOW to FAST
96-127 LEDs ON
128-159 Pulse Effect In Sequence SLOW to FAST
160-191 LEDs ON
192-223 Random Strobe Effect SLOW to FAST
224-255 LEDs ON
