Specifications for the tablet
Dimensions
Length 209.48 mm
Width 130.4 mm
Thickness 19.9 mm
Display
Type LCD
Screen size (diagonal) 8.8 inches
Resolution 2560 × 1600
Supported refresh rates
• 60 Hz
• 144 Hz
Brightness 500 nits
Connectors and slots
Combo audio jack
• Diameter: 3.5 mm
• Supported plug:
– 3-pole, TRS
– 4-pole, TRRS (CTIA and OMTP)
microSD card reader
• Quantity: 1
• Interface: UHS-II
USB Type-C
• Quantity: 2
• Maximum power output: 5 V, 1 A
• Supported signaling protocols:
– USB 2.0 480 Mbps
– SuperSpeed+ USB 10 Gbps
– DisplayPort 1.4
– Thunderbolt 3 40 Gbps
– USB4 40 Gbps
ac power adapter
Input 100 V ac–240 V ac, 50 Hz–60 Hz
Output voltage 20 V
Maximum output current 3.25 A
Maximum output power 65 W
10 User Guide
