802VLZ4
4
802VLZ4
Features
• 8-channel mixer featuring our
signature high-headroom, low-noise design
• 3 boutique-quality Onyx mic preamps
• Ultra-wide 60 dB gain range
• 128.5 dB dynamic range
• +22 dBu line input handling
• Extended frequency response
• Distortion under 0.0007%
[20 Hz – 50 kHz]
• Improved RF rejection, perfect for broadcast
applications
• Phantom power for condenser mics
• 8 high-headroom line inputs
• Selectable instrument inputs on first two
channels – no DI box needed
• 3-band EQ (80 Hz, 2.5 kHz, 12 kHz)
• 18 dB/oct 100 Hz low-cut filter on
mic input channels
• Aux send, level, pan and PFL solo on each
channel
• Stereo return for connecting FX processor or
other stereo source
• ALT 3/4 stereo bus for added routing flexibility
• Control room / phones source matrix
• High-resolution 12-segment stereo meters
• Sealed rotary controls resist dust
and grime
• “Built-Like-A-Tank” rugged steel
chassis with powder-coat finish
• High-visibility, high-contrast controls deliver
convenient “at-a-glance” visual feedback
Introduction
The 8-channel 802VLZ4 features the proven
performance of our flagship Onyx mic preamps in
a desk-friendly, ultra-compact design, perfect for
professional applications with a lower input need.
From every input to every output, the 802VLZ4 is
designed to provide the highest headroom and lowest
noise possible for maximum signal integrity.
Plus, it truly is “Built-Like-A-Tank” with a ridiculously
rugged solid steel chassis and high-contrast controls for
ultimate tactile control.
And with features like instrument level inputs,
phantom power and level metering, the 802VLZ4 offers
a true step-up performance and durability that's ideal
for your professional application.
How To Use This Manual
After this introduction, a getting started guide will
help you get things set up fast. The hookup diagrams
show some typical setups, while the remaining sections
provide details of the 802VLZ4 mixer.
This icon marks infor mation that is critically
important or unique to the 802VLZ4.
For your own good, read and remember them.
This icon will lead you to in-depth
explanations of features and some practical
tips. They usually have some valuable nuggets
of information.
This icon draws attention to certain features
and functions relating to the usage of the
802VLZ4.
Need help with your mixer?
• Visit www.720trees.com and click 'Contact Tech Support' to find: FAQs, manuals,
addendums, and other documents.
• Email us at: [email protected].
• Telephone 1-800-898-3211 to speak with one of our splendid technical support
representatives (Monday-Friday, during normal business hours, Pacific Time).
