Wagan SlimLine 2000W 12 VDC to 115 VAC Power Inverter - Manual (Page 2)

Slimline ™ Power Inverters by Wagan Tech ®
www.wagan.com
1
INTRODUCTION
Thank you for purchasing a Wagan Tech ® Slimline ™ Power Inverter. With minimal
care and proper treatment, it will provide years of reliable service.
This power inverter converts direct current (DC) to alternating household current
(AC). This inverter operates from a DC power source only. The level of direct
current allowed by this inverter varies by model. Please refer to the chart below:
Item No.
3724
Item No.
3724-4
Item No.
3724-8
12V DC Input 24V DC Input 48V DC Input
In an industry where the actual wattage output varies so greatly, Wagan Tech
is proud to introduce TrueRated Power ™ technology. All our inverters feature
TrueRated Power. That simply means power tested and rated at a period of
24 hours continuous usage under full load. Many competing products claim
“continuous duty”, when they are often only 20 minutes of “continuous” duty at
full output. We also build our inverters with High Peak Surge rating to support
motorized appliance start up.
Read and understand this manual before installing and operating this inverter.
Keep this manual for future use.
FEATURES
• Two LED indicators display the operating status of the inverter.
• Multiple AC outlets allow for more than one appliance to be powered at
the same time.
• Mounting holes allow for safe stable installation.
• High Peak Power: Allows you to power appliances that require large initial
start-up wattage.
• Low Battery Alarm: The inverter sounds an audible alarm then turns itself
off if the battery voltage becomes too low.
• Auto Shutdown/Reset Protection: The inverter temporarily shuts itself down
to protect itself from overheating.
• Overload/Short Circuit Protection: The inverter automatically turns itself off
if the connected load is too large or if it shorts.
