Operation Manual
30
Step 1 Select > Camera > Encode > Overlay > Location .
Figure 6-17 Location
Step 2 Click next to Enable , enter the location information, and then select alignment. The
text is displayed in the video image.
Click to add the text overlay, and you can add 13 lines at most.
Step 3 Move the text box to the position that you want in the image.
Step 4 Click Apply .
6.2.2.2.5 Configuring Font Properties
You can enable this function if you need to adjust the font size in the video image.
Step 1
Select > Camera > Encode > Overlay > Font Properties .
Figure 6-18 Font properties
Step 2 Select the font color and size.
You can set the RGB value to customize the font color.
Step 3 Click Apply .
6.2.2.2.6 Configuring Picture Overlay
You can enable this function if you need to display picture information on the video image.
Text overlay and picture overlay cannot work at the same time.
