Operation Manual
64
Figure 6-58 Voltage detection
Step 2 Click to enable the voltage detection function.
When enabling Overlay , the alarm icon is displayed by overlapping when the alarm is
triggered.
Step 3 Set alarm linkage actions. For details, see "6.4.1.2 Alarm Linkage".
Step 4 Click Apply .
6.4.3 Setting Video Detection
Check whether there are considerable changes on the video by analyzing video images. In case of
any considerable change on the video (such as moving object and fuzzy image), the system
performs an alarm linkage.
6.4.3.1 Setting Motion Detection
The system performs an alarm linkage when a moving object appears in the image and its moving
speed reaches the configured sensitivity.
● If you enable motion detection and smart motion detection simultaneously, and configure the
linked activities, the linked activities take effect as follows:
◇
When motion detection is triggered, the camera will record and take snapshots, but other
configured linkages such as sending emails, PTZ operation will not take effect.
◇
When smart motion detection is triggered, all the configured linkages take effect.
● If you only enable motion detection, all the configured linkages take effect when motion
detection is triggered.
Step 1 Select > Event > Video Detection > Motion Detection .
