Operation Manual
46
Parameter Description
Health Mail
The system sends test mail to check if the connection is successfully
configured. Click
and configure the Sending Interval , and then
the system sends test mail as the set interval.
For the configuration of major mailboxes, see Table 6-16.
Table 6-16 Description of major mailbox configuration
Mailbox SMTP server Authentication Port Description
gmail
smtp.gmail.c
om
SSL 465
You need to enable SMTP service
in your mailbox.
TLS 587
Step 4 Click Apply .
6.3.6 UPnP
UPnP (Universal Plug and Play) is a protocol that establishes mapping relation between local area
and wide area networks. This function enables you to access local area device through wide area IP
address.
Prerequisites
● Make sure the UPnP service is installed in the system.
● Log in the router, and configure WAN IP address to set up internet connection.
● Enable UPnP in the router.
● Connect your device to the LAN port of the router.
● Select > Network > TCP/IP , in IP Address , enter the local area IP address of the router or
select DHCP and acquires IP address automatically.
Procedure
Step 1 Select > Network > UPnP .
Figure 6-37 UPnP
Step 2 Click next to Enable , and there are two mapping modes: Custom and Default .
● Select Custom , click and then you can change external port as needed.
