Vivotek S Series IZ9361-EH 1080p Outdoor Network Bullet Camera with Heater - Manual (Page 234)

VIVOTEK
234 - User's Manual
© 2020 VIVOTEK INC. All Right Reserved
80
NAME VALUE SECURITY
(get/set) DESCRIPTION
display image.
If the value is a positive number, the
video quality of ROI is better than the
non-ROI areas. The level is from 1 to
5. Level 5 is the maximum level of the
quality difference between the ROI
and non-ROI areas.
If the value is a negative number, the
video quality of non-ROI areas is
better than the ROI. The level is from
-1 to -5. Level -5 is the maximum level
of the quality difference between the
ROI and non-ROI areas.
Group:
videoin_c<0~(n-1)>_s<0~(m-1)>_h264_smartstream2_win_i<0~(k-1)>
(capability_smartstream_support=1, capability_smartstream_version>=2.0 and
capability_smartstream_mode_manual = 1)
Group: videoin_c<0~(n-1)>_s<0~(m-1)>_h265_smartstream2_win_i<0~(k-1)>
(capability_smartstream_support=1, capability_smartstream_version>=2.0 and h265 is listed in
"capability_videoin_codec" and capability_smartstream_mode_manual = 1)
n denotes the value of "capability_nvideoin",m denotes the value of " capability_nmediastream",k
denotes the value of "capability_smartstream_nwindow_manual".
NAME VALUE SECURITY
(get/set) DESCRIPTION
enable <boolean> 4/4 Enable or disable the window.
home 0~320,0~240 4/4 Left-top corner coordinate of the
window.
size 0~320x0~240 4/4 Width and height of the window
7.8.1.1 Alternative Video Input Profiles per Channel
In addition to the primary setting of video input, there can be alternative profile video input setting
for each channel which might be for different scene of light (daytime or nighttime).
Group:
videoin_c<0~(n-1)>_profile_i<0~(m-1)> for n channel products and m profile
n denotes the value of "capability_nvideoin" and m denotes the value of
"capability_nvideoinprofile"
(capability_nvideoinprofile> 0)
