166
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
rotationaffect -
<product
dependent>
0/7 When rotation is enabled, some features
may become malfunction or be forced to a
given value. The affected functions are list
here.
The format is "Affect API
name":"Policy":"Description"
"Policy" can be categorized into following
groups:
- (disabled) : UI turns grey and users can't
select it.
- (unchanged) : UI keeps the status as before
and user can't change it.
- (hidden) : UI is hidden.
- (fixed) : UI is fixed to one selection or
value.
- (ranged) : UI is fixed to multiple selections
or values.
- (enabled) : UI is checked.
- (notsupport) : the affected function is not
available.
"Affect API name" can be described in
hierarchy, such as
"exposurewin.mode.blc:disabled:" which
means blc exposure window is disabled. API
name can be one word as well, such as
"exposurelevel:fixed:6" which means
exposurelevel is fixed to level 6.
"Description" can be a nonnegative integer
or string or NULL.
"-" means no feature is affected.
* When "rotation"=0, this value must be "-"
* We support this parameter when the
version number (httpversion) is equal or
greater than 0304b.
© 2020 VIVOTEK INC. All Right Reserved
167
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
rotationangle <string> 0/7 The different angles which camera supports
for rotation.
* Only avaliable when
"capability_videoin_c<0~(n-1)>_rotation" is
1.
* We support this parameter when the
version number (httpversion) is equal or
greater than 0309b.
orientation flip,mirror,rotatio
n
<product
dependent>
0/7 Indicates the camera supports flip, mirror or
rotation.
* We support this parameter when the
version number (httpversion) is equal or
greater than 0309b.
streamcodec <positive integer> 0/7 Represent supported codec types of each
stream.
This contains a list of positive integers, split
by comma. Each one stands for a stream,
and the definition is as following:
Bit 0: Support MPEG4.
Bit 1: Support MJPEG
Bit 2: Support H.264
Bit 3: Support H.265
mode 0,<positive
integer>
0/7 Indicate current video mode.
nmode <positive integer> 0/7 Indicate how many video modes supported
by this channel.
maxsize <WxH> 0/7 The maximum resolution of all modes in this
channel, the unit is pixel.
nprivacymask 0, <positive
integer> 0/7 Number of privacy mask per channel
nresolution <positive integer> 0/7 The maximum resolution options (listed in
"resolution") in current video mode.
