7
Detachable antenna
MIC IN jack
Connects to the supplied 3.5mm lavalier
microphone.
LINE IN jack
Connects to the line level devices.
AUDIO indicator / IR (infrared detector)
AUDIO indicator: Indicates the audio input
level. IR (infrared detector): Receives the
frequency from the receiver.
Solid Blue: Audio input level is appropriate.
Flashing Red: Audio is muted (i.e. disabled).
For details on setting the mute function,
please refer to "Set Mute key" (page 8).
POWER indicator
Indicates the battery level as follows: Solid
Blue: Sufficient battery level.
Solid Red: Low battery.
Charging Status:
Flashing Red: Charging.
Solid Blue: Fully charged.
OLED display
For display menus, please refer to the "OLED
Display Operation Guide" (page 8) for more
details.
Power / Mute button
Power ON:
Press button for one second or longer
Power OFF:
Press button until it turns off
Mute ON/OFF:
Short press button
SET button
Long press the SET button to enter the
displayed menu. Then, short press the SET
button to confirm your option or long press
again to exit without saving.
+ or – button
Selects functions or values shown on the
display.
USB-C charging port (DC 5V)
Attaching Accessories
1. Attaching a belt clip
Insert one end of the belt clip into one of two
holes on either side of the transmitter, and then
insert the other end into the hole on the other
side.
2. Connecting the microphone
For a secure connection, turn to lock the
connector.
Note: Please turn off the transmitter before
attaching or removing the microphone.
