N.A. WELDING CABLE MUST BE SIZED FOR CURRENT AND DUTY CYCLE OF APPLICATION.
N.B. DIAGRAM SHOWS ELECTRODE POSITIVE. TO CHANGE POLARITY, TURN POWER "OFF",
REVERSE ELECTRODE AND WORK CABLE AT POWER SOURCE.
N.C. INSULATE EACH UNUSED LEAD INDIVIDUALLY.
TO
WORK
-
+
14 PIN
AMPHENOL
N.C.
76
82
K867 UNIVERSAL
ADAPTER PLUG
81
SPARE
2
4
41
42
31
32
GND
21
77
75
REMOTE OUTPUT CONTROL
NOT USED ON INVERTEC
24 VAC / 1 AMP
CONNECT TOGETHER FOR
WELDING OUTPUT
42 VAC / 5.5 AMP
115 VAC / 2 AMP
INVERTEC FRAME CONNECTION
N.D.
N.D. FOR WIRE FEEDERS THAT RETURN A SIGNAL FOR WELDING OUTPUT, USE ISOLATION
RELAY TO CLOSE LEADS 2 & 4.
2
4
TO
K867
ELECTRODE CABLE
WIRE FEEDER VOLTMETER CONNECTION
CONNECTS TO (WORK TERMINAL) OF INVERTEC
TO
WIRE FEEDER
10K
MIN.
Only qualified persons should install, use or
service this machine.
using the disconnect switch at the fuse box
WARNING
Turn off input power to the Welding Power Source
Before connecting the wire feeder.
ELECTRIC
SHOCK
CAN KILL
INVERTEC
POWER SOURCE
WITH 115VAC
AUXILIARY POWER
S19406
12-10-93A
K867 UNIVERSAL ADAPTER / INVERTEC - CONNECTION DIAGRAM
