31
–
N.C. INSULATE EACH UNUSED LEAD INDIVIDUALLY.
TO
WORK
-
+
14 PIN
AMPHENOL
SPARE
82
81
42
41
31
32
2
4
21
GND
75
76
77
31
32
2
4
21
GND
N.C.
K867 UNIVERSAL
ADAPTER PLUG
N.D.
N.D. SPLICE LEADS AND INSULATE.
Only qualified persons should install, use or
service this machine.
using the disconnect switch at the fuse box
WARNING
Turn off input power to the Welding Power Source
Before connecting the wire feeder.
ELECTRIC
SHOCK
CAN KILL
N.A. WELDING CABLE MUST BE SIZED FOR CURRENT AND DUTY CYCLE OF APPLICATION.
N.B. DIAGRAM SHOWS ELECTRODE POSITIVE. TO CHANGE POLARITY, TURN POWER "OFF", REVERSE
ELECTRODE AND WORK CABLE AT POWER SOURCE. SET METER POLARITY SWITCH ON REAR
OF INVERTEC TO COINCIDE WITH POLARITY USED. SET LN-9 GMA POLARITY SWITCH ALSO.
N.F. FOR GMAW WELDING, INSTALL PULSE POWER FILTER KIT K442-1 IN LN-9 GMA.
A
K196
INPUT CABLE
ELECTRODE CABLE
TO LN-9 GMA
INVERTEC
POWER SOURCE
WITH 110/115V AUX.
LN-9 GMA WITH
K608-1 AND
K442-1 KITS.
N.E. INSTALL K608-1 ADAPTER IN LINE WITH P10 TO LN-9 GMA VOLTAGE BOARD AND SECURE TO
ADJACENT HARNESS WITH WIRE TIE PROVIDED. TURN "START" TRIMMER ON VOLTAGE BOARD FULLY ’CCW’.
S20608
P10’,J10
2
3
4
5
6
7
10
11
12
P10,J10’
2
3
4
5
6
11
12
7
3.9K
K608-1
CONNECTION
DETAIL
530A
521
500
500
524
C
B
533
C
B
9-11-92
LN-9 GMA WITH K196 CABLE AND K867 PLUG TO INVERTEC - CONNECTION DIAGRAM
