Pre-assembly diagram (full), Bill of materials – Buyers 1501100 User Manual
Page 2
Advertising
Quality since 1946
2
Bill of Materials
1
1
Cab Hoop
2
1
Front Crossbar
3
1
Center Crossbar
4
1
Rear Crossbar
5
2
Front Siderail (universal)
6
2
Rear Siderail (universal)
7
2
Leg with Gusset A(directional)
8
2
Leg with Gusset B(directional)
9
2
Mounting Foot A(directional)
10
2
Mounting Foot B(directional)
11
2
Rear Crossbar Mounting Brackets, Driver Side
12
1
Rear Crossbar Mounting Bracket, Passenger Side
13
4
Siderail Connection Plates
Item
QtY.
DescrIptIon
1
2
3
4
5
6
7
8
9
10
12
13
5
6
10
9
7
8
11
13
Pre-Assembly Diagram (Full)
