4. While holding the assembly, turn the appropriate
bulb holder counterclockwise to release it from the
housing.
5. Remove the bulb from the holder by pushing it in
and turning it counterclockwise. The turn signal
bulb must have amber colored glass.
6. Install the new bulb into the bulb holder by pushing
it into the holder and turning it clockwise.
7. Insert the new bulb into the bulb holder and install
the bulb holder into the lamp housing, ensuring that
the holder locks securely into place.
8. Ensure that the lamp assembly clips are seated
correctly. Fit the housing to the body, ensuring
that the locating pegs snap into the clips and install
and tighten the attaching nuts to the correct
torque.
9. Check the light operation.
Replacement Bulbs
Exterior Lamp Bulb Number
Back-up Lamp 1156
Front Sidemarker Lamp 168
Front Turn Signal and
Parking Lamp
1157NA
Headlamps
High-Beam
Low-Beam H9
H11
Rear Turn Signal 1156NA
Stop/Taillamp 1157
For any bulb not listed here contact your dealer.
Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected at least
twice a year for wear or cracking. See Owner Checks
and Services on page 6-9 for more information.
To replace the wiper blade assembly:
1. Lift the wiper up from the windshield and set into
the vertically-locked position.
2. Press the tab that holds the wiper blade to the arm.
3. Slide the blade down and off the arm.
4. Slide in the new blade and snap into place.
