Caution – Subaru 2003 Baja User Manual
Page 118
BAJA U.S.A..A2310BE–A
3-8
To change the mode indication, briefly push the knob.
Each press of the knob changes the function alternately.
A trip meter
B trip meter
To set the trip meter to zero, select either the A trip or B trip meter and
push the knob and keep it pushed for more than 1 second.
NOTE
If the connection between the combination meter and battery is bro-
ken for any reason such as vehicle maintenance or fuse replace-
ment, the data recorded on the trip meter will be lost.
J Tachometer
CAUTION
Do not operate the engine with the pointer of the tachometer in
the red zone. In this range, fuel injection will be cut by the engine
control module to protect the engine from overrevving. The
engine will resume running normally after the engine speed is
reduced below the red zone.
The tachometer shows the engine speed in thousands of revolutions per
minute.
J Outside temperature indicator (if equipped)
The outside temperature indicator shows the outside temperature in a
range from –22
°F to 122°F (–30°C to 50°C).
The indicator can give a false reading under any of the following condi-
tions:
D When there is too much sun.
D During idling; while running at low speeds in a traffic jam; when the
engine is restarted immediately following a shutdown.
D When the actual outside temperature falls outside the specified indi-
cator range.
