Introduction
Features
The Atlona AT-HD-IR40SR HDMI v1.3 Extender over 2 CAT5e Cables
with IR boosts up your video/audio transmission distance up to 60m / 200ft
in HDTV 720p / 1080i format. With two low cost CAT-5/5e/6 cables, users
can readily extend HDTV sources from DVD players, Blu-ray Disc Player,
PS3, PC, and any other kinds of sources compliant with TMDS to distant
display monitors including HDMI / DVI enabled TV sets or LCD PC moni-
tors. This cost effective flexibility makes HDCP compliant DVD players or
PS3 transmit high quality video and audio to a greater distance at the mini-
mal cost, when integrating several components apart. In addition, with the
included infrared (IR) receiving and transmitting extension cables to facili-
tate the control path, users can enjoy high quality audio/video and control
the HDMI sources from the remote site instantly.
The AT-HD-IR40SR includes two units: AT-HD-IR40S as the transmitting
unit and AT-HD-IR40R as the receiving unit. The transmitting unit is used
to transfer the HDMI/DVI and IR signals input and carry the signals through
two RJ-45 connectors over two low cost CAT-5/5e/6 cables. The receiving
unit is responsible for equalizing transferred TMDS multimedia data and
re-sending IR signals. The transmission distance between the sending and
receiving units can be up to 60m / 200ft at 720p / 1080i and 40m / 130ft at
1080p. With equalization control on the receiving unit, users can adjust the
equalization scale to the received TMDS signals, and therefore optimize the
transmission distance between source and destination.
• HDMI 1.3a compliant
• Extends the transmission distance up to 60m / 200ft from the sources at 1080i or 720p
• Extends the transmission distance up to 40m / 130ft from the sources at 1080p
• Provides independent DDC channel, fully HDCP compliant
• Minimizes the cable skew by adjustable 8-level equalization control
• Embedded IR control path
