Panel Descriptions
HDMI IN: Connect a HDMI source with a HDMI M-M cable here
IR EXTENDER: Extendable IR sending socket
TMDS: Plug in a CAT-5/5e/6 cable that needs to be linked to the TMDS connector
of the receiving unit AT-HD-IR40R.
DDC: Plug in a CAT-5/5e/6 cable that needs to be linked to the DDC connector of
the receiving unit AT-HD-IR40R.
5V DC: Connect to 5V DC power supply.
Front View – Transmitting Unit AT-HD-IR40S
Rear View – Transmitting Unit AT-HD-IR40S
IR EXTENDER
HDMI IN
5V DC
TMDS
DDC
