1 2
Package Contents
Technical Specifications
• 1x HDMI transmitting unit (AT-HD-IR40S)
• 1x HDMI receiving unit (AT-HD-IR40R)
• 2x IR extension cable (IR sender & IR receiver)
• 1x 5V 4A power adapter
• 1x User Manual
• Video Bandwidth: 10.2 Gbps (HDMI 1.3a)
• Input connector:
Transmitter: 1x female HDMI connector (19 pin type)
Receiver: 2x RJ-45
IR Socket: Electro-optical Characteristics: (Ta=25°C)
• Input TMDS signal: 1.2 volts (peak-to-peak)
• Input DDC signal: 5 volts (peak-to-peak)
• HDMI Connector: 19 pin type female connector
• Power Supply: 5V 4A DC
• Power Consumption: 6 Watts (max)
• Dimensions: 85mm x 60mm x 25mm / 3.3”x2.4”x1” (L x W x H)
• Weight: 240g / 8.5oz
• Output connector:
Transmitter: 2x RJ-45
Receiver: 1x female HDMI connector (19 pin type)
IR Socket: Electro-optical Characteristics: (Ta=25°C)
Parameter TYP. UNIT
B.P.F Center Frequency 38 KHz
Parameter TYP. UNIT
B.P.F Center Frequency 38 KHz
