TEK 380-HD Conference Camera
12
TEKVOX, Inc.
–512.808.0845
Austin, TX 78746
IR Address Select
IR Select
SW2( 4-5 Bit
Switch State
DIP-4
DIP-5
1
OFF
ON
2
ON
OFF
3
ON
ON
Notes: When the IR select value is zero, any address of the remoter controller can control the camera.
Installation
The Camera can be mounted on the wall or ceiling using the bracket or tripod mount. When mounted to a
wall, you must use a shelf type mount and not mount the camera directly to the wall. Do not use a heavy
HDMI cable directly connected to the camera. Instead, use a smaller size adapter cable to reduce strain on
the HDMI connector.
Size
