TEK 380-HD Conference Camera
16
TEKVOX, Inc.
–512.808.0845
Austin, TX 78746
Command
Type
Command
Packet
Comments
IR Receive
On
Off
8x 01 06 08 02 FF
8x 01 06 08 03 FF
IR Receiver On/Off
Color system
RGB
YPbPr
8x 01 7E 01 03 00 00 FF
8x 01 7E 01 03 00 01 FF
Color-reproduction format setting
Pan-tilt Drive
Up
Down
Left
Right
Up Left
Up Right
Down Left
Down Right
Stop
Absolute Position
Relative
Position
Home
Reset
8x 01 06 01 VV WW 03 01 FF
8x 01 06 01 VV WW 03 02 FF
8x 01 06 01 VV WW 01 03 FF
8x 01 06 01 VV WW 02 03 FF
8x 01 06 01 VV WW 01 01 FF
8x 01 06 01 VV WW 02 01 FF
8x 01 06 01 VV WW 01 02 FF
8x 01 06 01 VV WW 02 02 FF
8x 01 06 01 VV WW 03 03 FF
8x 01 06 02 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
8x 01 06 03 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
8x 01 06 04 FF
8x 01 06 05 FF
VV: Pan speed 0 x01 (low speed) to 0 x18
(high speed)
WW: Tilt Speed 0 x 01 (low speed) to 0 x14
(high speed)
YYYY: Pan Position 0000 to 07E0 (left
0000)
ZZZZ: Tilt Position 0000 to 01C8 (down
0000)
Pan-tilt
Limit Set
Limit Set
Limit Clear
8x 01 06 07 00 0W
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
8x 01 06 07 01 0W
07 0F 0F 0F 07 0F 0F 0F FF
W: 1 Up Right 0: Down Left
YYYY: Pan Position 0000 to 07E0 (left
0000)
ZZZZ: Tilt Position 0000 to 01C8 (down
0000)
