Analog Way Smart Vu - SVU300 Programmer's Guide - Manual (Page 57)

57
Group Name CmdResp Description
Read /
Write Min
Value Max
value Default
value
Values Index #1 Index #2
AUDIO_SDI_CHAN_LEFT Ac Ac
ID of the Sdi channel to desembed
for left channel
Rd/Wr 0 15 0
0 = Group A – Channel 1
1 = Group A – Channel 2
2 = Group A – Channel 3
3 = Group A – Channel 4
4 = Group B – Channel 1
5 = Group B – Channel 2
6 = Group B – Channel 3
7 = Group B – Channel 4
8 = Group C – Channel 1
9 = Group C – Channel 2
10 = Group C – Channel 3
11 = Group C – Channel 4
12 = Group D – Channel 1
13 = Group D – Channel 2
14 = Group D – Channel 3
15 = Group D – Channel 4
10 = Channel 11 –
SDI 1
11 = Channel 11 –
SDI 2
12 = Channel 11 –
SDI 3
13 = Channel 12 –
SDI 4
AUDIO_SDI_CHAN_RIGHT AC AC
ID of the Sdi channel to desembed
for right channel
Rd/Wr 0 15 1
0 = Group A – Channel 1
1 = Group A – Channel 2
2 = Group A – Channel 3
3 = Group A – Channel 4
4 = Group B – Channel 1
5 = Group B – Channel 2
6 = Group B – Channel 3
7 = Group B – Channel 4
8 = Group C – Channel 1
9 = Group C – Channel 2
10 = Group C – Channel 3
11 = Group C – Channel 4
12 = Group D – Channel 1
13 = Group D – Channel 2
14 = Group D – Channel 3
15 = Group D – Channel 4
10 = Channel 11 –
SDI 1
11 = Channel 11 –
SDI 2
12 = Channel 11 –
SDI 3
13 = Channel 12 –
SDI 4
AUDIO_DESEMBEND_LOCKED As As
Information of audio channel
presence for SDI inputs
Rd 0 1 1 1 : Locked
10 = Channel 11 –
SDI 1
11 = Channel 11 –
SDI 2
12 = Channel 11 –
SDI 3
13 = Channel 12 –
SDI 4
