Chapter 6 : LCD SCREEN DESCRIPTION
6-1. INTRODUCTION
The LCD screen is composed of 2 modes: the STATUS MODE and the CONTROL MODE.
• The STATUS MODE indicates the input and the output status of the TRANS-SCALER XT ™ .
• The CONTROL MODE allows to select and adjust the parameters of the TRANS-SCALER XT ™ .
6-2. LCD CONTROL BUTTONS
The LCD screen is controlled by 3 buttons :
 CONTROL knob: To scroll thru the different menus.
EXIT / MENU button: • From the STATUS MODE, press this button to display the CONTROL MODE.
• From the CONTROL MODE, press this button to :
- return to the previous menu,
- return to the STATUS MODE (press several times),
- return without safeguarding the item.
ENTER button : • From the STATUS MODE, press this button to return to the last consulted menu.
• From the CONTROL MODE, press this button to confirm a selected item.
NOTE: When entering in the CONTROL MODE, the LCD window will automatically display the STATUS MODE
after 60 seconds of inactivity of the front panel buttons.
6-3. STATUS MODE
When switched ON, the LCD screen shows the product's name and reference as follows:
PRODUCT NAME TRANS-SCALER XT MAIN STATUS MENU
PRODUCT MODEL TSC 550
Output SYNC= H&V c OUTPUT STATUS MENU
d 1024 x 768p
Input s.video 1 e INPUT STATUS MENU
f NTSC 3.58 / 60
c OUTPUT SYNC TYPE (H&V = Separate H &V Sync., COMP = Composite Sync.).
d OUTPUT FORMAT.
e DISPLAYED INPUT.
f VIDEO STANDARD OF THE DISPLAYED INPUT.
