TRANS-SCALER XT™ Chapter 1 : INTRODUCTION
PAGE 5
ENGLISH
TRANS-SCALER XT ™
Chapter 1 : INTRODUCTION
1-1. SUPPLIED EQUIPMENT
• 1 TRANS-SCALER XT ™ .
• 1 Set of 19" brackets.
• 1 AC Power supply Cord.
• 1 RCA male / RCA male cable.
• 1 VGA cable (HD15 Male / HD15 Male).
• 1 S.VIDEO (Y/C) cable (4-pin mini DIN Male/ Male).
• 1 RCA Female / BNC male adapter.
• 1 User’s manual.
• 1 Remote Control Software (3.5” disk).
1-2. GENERAL INFORMATION
The TRANS-SCALER XT ™ combines the functions of a Video Scaler with a Multi-input Video Switcher. In
addition, a Computer or External input is provided for direct display of your Presentations or Internet
applications.
• The TRANS-SCALER XT ™ is a new SCALER / LINE DOUBLER / QUADRUPLER / MULTIPLIER which
significantly increases the Video image resolution and brightness. The High Quality Digital decoder includes a new
advanced Comb Filter, a robust sync. detection and a 3D auto-adaptive de-interlacing scheme (for motion artifacts),
with correction of the "film to video" transfer (3/2 pulldown for NTSC). It provides you with a "cinema like" image.
• In addition, and according to your requirements, you can adjust special image parameters like the Sharpness for detail
emphasis, and the Gamma corrector, which optimizes your Display "Near Black" Luma response. You can also select a
filter which removes unwanted alias frequencies found in some LCD video-projectors.
• The input source aspect-ratio (4/3 - Letterbox - Widescreen Anamorphic) can be selected, as well as the 4/3 & 16/9
Screen selection to avoid "resizing" the video-projector ZOOM when viewing 4/3 Sources on a 16/9 display.
• It provides a cost effective, time base corrected scaling solution for the A/V Pro & Home Theater applications.
• The black & White composite is accepted (for industrial, security, camera applications).
