TRANS-SCALER XT™
PAGE 25
Chapter 11 : TROUBLESHOOTING
SYMPTOM CAUSE CORRECTION PLEASE SEE
• The power cord is disconnected. • Connect the AC power cord to the
TRANS-SCALER XT and to the power
outlet.
• Chapter 4-1. • NO POWER
The LCD is OFF.
• The TRANS-SCALER XT ™ is
“POWER OFF”.
• Press on the power switch on the front
panel. • Chapter 4-1.
• The input source is not selected
correctly. • Select the input source, with the front
panel push button, according to the
equipment connected to the TRANS-
SCALER XT
™ .
• Chapter 4-1.
• The input source is OFF. • Power ON the input source. • Input source
user’s manual.
• NO PICTURE
The LCD input status
displays “No video”.
For example :
S.Video 1 = No video.
• The input source is
disconnected. • Connect the input source to the TRANS-
SCALER XT
™ .
• Chapter 4-1.
• The display device is OFF. • Power ON the display device. • Display device
user’s manual.
• The display device is
disconnected. • Connect the DISPLAY OUTPUT of the
TRANS-SCALER XT
™ to the PC/RGB
input of your display device.
• Display device
user’s manual.
• The DATA (PC/RGB) input of
your display device is not selected
correctly. • Select the DATA (PC/RGB) input on
your display device. • Display device
user’s manual.
• The display device is not
compatible with the selected
output format. • Check if the Display device is
compatible with the selected output
format. • Chapter 7 : LCD
menu # 2-1.
• Display device
user’s manual.
• NO PICTURE
The LCD input status
displays the right status
of the video. (For example :
S.Video 1 = NTSC) but no
image appears on the
display device.
• The display device is not
compatible with the selected
output Sync. Type. • Check if the display device is compatible
with the selected output Sync. type. • Chapter 7 : LCD
menu # 2-2.
• Display device
user’s manual.
• The RS-232 cable is
disconnected. • Connect the serial port of your computer
to the RS-232 connector of the TRANS-
SCALER XT
™ (using a straight cable).
• Chapter 9-1. • The RS-232 software
displays “TRANS-
SCALER XT not
connected”.
• The serial port is not selected
correctly. • Select the serial port in the Controls
menu. • Chapter 9-3.
Chapter 12 : OPTIONAL ACCESSORIES
DESIGNATION LENGTH REFERENCE
S-VIDEO (Y/C) CABLE (4 pin mini DIN M/M) 5 m / 16 ft 10093
S-VIDEO (Y/C) CABLE (4 pin mini DIN M/M) 10 m / 33 ft 10094
VGA TO 5 BNC CABLE (HD15 M / BNC M) 1.8 m / 6 ft 10023
VGA TO 5 BNC CABLE (HD15 M / BNC M) 3 m / 10ft 10024
VGA TO 5 BNC CABLE (HD15 M / M) 6 m / 20 ft 10022
VGA TO 5 BNC CABLE (HD15 M / M) 10 m / 33 ft 10076
SET OF MAC (RGB HV) TO VGA CABLE ADAPTER (DB15 M / HD15 F) 2 x 0.3 m / 2 x 1 ft 10045
REMOTE CABLE (DB9 M/F) 3 m / 10ft 10110
REMOTE CABLE (DB9 M/F) 5 m / 16 ft 10111
REMOTE CABLE (DB9 M/F) 10 m / 33 ft 10112
