TRANS-SCALER XT™ Chapter 10 : PROGRAMMER'S GUIDE
PAGE 23
10-5. VALUES DESCRIPTION
ASCII
COMMAND
RESPONSE
TO HOST
COMMAND DESCRIPTION VALUE DESCRIPTION
Input commands
C CH Input selection. None
0
1
2
3
4
5
6
Read the selected input.
Select COMPOSITE 1 input.
Select COMPOSITE 2 input.
Select S.VIDEO 1 input.
Select S.VIDEO 2 input.
Select RGBS input.
Select COMPONENT (YUV) input.
Select COMPUTER input.
p PSTD Input standard selection for the
Composite and S.VIDEO inputs. None
0
1
2
3
4
14
Read the input type.
Set to NTSC(3.58/60).
Set to PAL (4.43 / 50).
Set to SECAM (50).
Set to Black & White (60).
Set to Black & White (50).
Set to AUTO.
L TTL TTL/75 Ω selection (RGBS input) None
0
1
Read the RGB/S input status.
Set the RGB/S sync. to 75
Ω load.
Set the RGB/S sync. to TTL.
Output commands
F OFMT Output format selection. None
0
1
2
3
4
5
6
7
Read the output format.
Set to Doubler.
Set to 852 x 480p
Set to 800 x 600p.
Set to 1280 x 720p.
Set to 1024 x 768p.
Set to Quadrupler.
Set to 1365 x 768p.
Set to 1365 x 1024p.
f OSYNC Output Sync selection. None
0
1
Read the output sync. type.
Set to H & V separate sync.
Set to Composite sync.
s SCRN Type of Screen selection. None
0
1
Read the output screen type.
Set to 4/3 screen.
Set to 16/9 screen.
Image commands
P PCH Input selection for adjustment. Identical as C command
Q OVER Under/Overscan mode selection. None
0
1
Read the Under/Overscan mode.
Set to Overscan mode.
Set to Underscan mode.
a IASP Input Aspect Ratio selection. None
0
1
2
Read the selected input aspect ratio.
Select 4/3 standard.
Select letterbox.
Select Widescreen Anamorphic.
M GAM Gamma selection. None
0
1
2
3
Read gamma value.
Set gamma to –1.
Set gamma to 0.
Set gamma to 1.
Set gamma to 2
Controls commands
K BLKD Black delay selection. None
0
1
(…)
10
Read the black delay.
Set black delay to factory default value.
Set black delay value to 1 second.
Set black delay value to (…).
Set black delay value to 10 seconds.
y LOCK Front panel locking function. None
0
1
Read the front panel locking status.
Unlock the front panel.
Lock the front panel.
