17
2
Hardware Installation
Connectors
COM Express Connectors
The COM Express connectors are used to interface the NP905-
B16C COM Express board to a carrier board.
Connect the COM Express connectors, lcoated on the solder side of
the board, to the COM Express connectors on the carrier board.
Refer to the “Installing NP905-B16C onto a Carrier Board” section
for more information.
Refer to the following pages for the pin functions of these connec-
tors.
COM Express connectors
