24
2
Hardware Installation
Cooling Options
Heat Sink
Top View of the Heat Sink
Bottom View of the Heat Sink
• "1" to "6" denote the locations of the thermal pads
designed to contact the corresponding compo-
nents that are on NP905-B16C.
• Remove the plastic covering from the thermal
pads prior to mounting the heat sink onto NP905-
B16C.
5
2
3
4
1
6
