CommandPLUS Series Desktop Console Installation and Service Manual Installation
21 12/10
System Jumper Table
The purpose of Table 9 is to assist the installer in determining the correct placement of console slave
board jumpers, for various system configurations. Each CommandPLUS Series Desktop Console is
equipped with a minimum of one CSD slave board for ICP9004A (4 channels), 2 slave boards for
ICP9008A (8 channels) and 3 slave boards for ICP9012A (12 channels) operation.
Each channel can be individually configured to support 2-wire, 4-wire, bridging, or terminating modes of
operation (parallel or single console). Refer to Figure 5.
The CommandPLUS Series Desktop Console is shipped with all line termination resistors in place. For
parallel operation of multiple consoles, the last console on any particular line should have its 2W or 4W
termination jumpers in place and any intermediate console should have the line termination jumpers
removed.
Table 9. CSD Slave Unit Table
Function Jumper No. Position
Ch. 1, 5, 9 4W RX Termination JU603 IN
OUT
600 ohm (default)
Parked – Bridging Impedance
Ch. 2, 6, 10 4W RX Termination JU607 IN
OUT
600 ohm (default)
Parked – Bridging Impedance
Ch. 3, 7, 11 4W RX Termination JU611 IN
OUT
600 ohm (default)
Parked – Bridging Impedance
Ch. 4, 8, 12 4W RX Termination JU615 IN
OUT
600 ohm (default)
Parked – Bridging Impedance
Ch. 1, 5, 9 TX Source Impedance
2W RX Termination Impedance
JU601 IN
OUT
600 ohm (default)
Parked – Bridging Impedance
(parallel console)
Ch. 2, 6, 10 TX Source Impedance
2W RX Termination Impedance
JU605 IN
OUT
600 ohm (default)
Parked – Bridging Impedance
(parallel console)
Ch. 3, 7, 11 TX Source Impedance
2W RX Termination Impedance
JU609 IN
OUT
600 ohm (default)
Parked – Bridging Impedance
(parallel console)
Ch. 4, 8, 12 TX Source Impedance
2W RX Termination Impedance
JU613 IN
OUT
600 ohm (default)
Parked – Bridging Impedance
(parallel console)
