F R A M E A S S E M B L Y
Step 2e
12 - Bearing Housing
16 - U-Bracket
27 - Handle Weldment
Part Descriptions
H - 1/2”-13UNC x 3 1/2” Hex Head Bolt (WZ)
J - 5/16”-18UNC x 1” Button Head Bolt (WZ)
AA - 1/2” Washer
AC - 5/16” Washer
AF - 5/16” Lock Washer
BA - 1/2” Nylok Nut
CB - 25.4mm dia. x 63mm lg. Axle
CN - Handle
CP - 25.4mm dia. x 148mm lg. Axle
CQ - 3/4” Thrust Washer
CR - 3/4” Thrust Bearing
Hardware Descriptions
Page - 13 HD1700 Assembly
OW N E R S
M A N U A L
Continue assembly by inserting (CP) into (CN). Then attach both to
(27). Now attach (27) to (16). Insert (CB) into (12) and attach (16) to
(12). bolts. Check to see that the Handle
Weldment and U-Bracket rotates freely. If not, turn back the nut on the
bolt for the axle just enough so that the Handle Weldment and U-Bracket
rotates freely.
Wrench Tighten NOTE:
