C A B L E I N S T A L L A T I O N S
Step 2g
5 - Front Support
25 - HD1700 Lat/Highrow Cable
Part Descriptions
K - 3/8”-16UNC x 2 1/2” Hex Head Bolt (WZ)
BB - 3/8” Nylok Nut
CC - 1/2” Flanged Spacer
CV - Cable Mount
Hardware Descriptions
Page - 17 HD1700 Assembly
OW N E R S
M A N U A L
Continue assembly by installing (25) to machine. Cable will be
secured to (5) with (CU). See Detail -A- for installation.
bolts. check to see that the Cable Mount rotates freely. If not,
turn back the nut on the bolt just enough so that the Cable Mount rotates
freely.
Wrench Tighten
NOTE:
