F R A M E A S S E M B L Y
Step 2i
1 - Weight Frame Upright
26 - Shield
Part Descriptions
S - 1/2”-13UNC x 4 1/2” Hex Head Bolt (WZ)
T - 1/4-20UNC x 5” Button Head Bolt (WZ)
AA - 1/2” Washer
AD - 1/4” Washer
BA - 1/2” Nylok Nut
BC - 1/4” Nylok Nut
CW - White Spacer
CX - HD1700 Placard (Left)
CY - HD1700 Placard (Right)
Hardware Descriptions
Page - 21 HD1700 Assembly
OW N E R S
M A N U A L
Finish assembly by attaching (26) to both (1)’s. Then attach (CX) to
(1). Repeat assembly for (CY). bolts.
Now that the Hd1700 machine is completely assembled take time to
assure that your unit is assembled square and perpendicular. To check
this use a Level to check that the Guide Rods are perpendicular in both
directions. If they are not perpendicular in both directions. It will be
necessary to loosen some Frame hardware to re-align the Frame and re-
tighten bolts.
Wrench Tighten
*IMPORTANT*
