P U L L E Y A S S E M B L Y
Step 2f
2 - Top Pulley Mount
5 - Front Support
8 - Resistance Lever Arm
Part Descriptions
D - 3/8”-16UNC x 3” Hex Head Bolt (WZ)
K - 3/8”-16UNC x 2 1/2” Hex Head Bolt (WZ)
L - 3/8”-16UNC x 1 3/4” Hex Head Bolt (WZ)
AB - 3/8” Washer
BB - 3/8” Nylok Nut
CC - 1/2” Flanged spacer
CD - 4 1/2” Pulley
CT - 11/16” Flanged Spacer
Hardware Descriptions
Page - 15 HD1700 Assembly
OW N E R S
M A N U A L
The following page shows each pulleys location and the hardware
used to install it. When installing each pulley, refer to the Cable
Installation diagram on page 18 to ensure the cable is routed properly
around each pulley and is on the correct side of any cable guard pins or
bolts. all bolts.
Wrench Tighten
