Step 2b – Hoist Fitness HD-1700 User Manual
Page 8
F R A M E A S S E M B L Y
Step 2b
2 - Top Pulley Mount
5 - Front Support
6 - Front Upright
7 - Gusset Plate
Part Descriptions
B - 1/2”-13UNC x 3” Hex Head Bolt (WZ)
C - 1/2”-13UNC x 3 1/4” Hex Head Bolt (WZ)
AA - 1/2” Washer
BA - 1/2” Nylok Nut
CA - Rubber Foot Pad
CS - 19mm dia. x 57.5mm lg. Axle
CT - 11/16” Flanged Spacer
Hardware Descriptions
Page - 7
HD1700 Assembly
OW N E R S
M A N U A L
Continue assembly by attaching both (7)’s to (6);
when
securing both (7)’s, and (5) together, slide (CT) into the holes on (7) and
(6) before securing with (B) to ensure proper alignment. (CT) acts as a
spacer for a pulley which is installed in a later step.. Attach (6) to (2) and
(5). Then insert (CS) into (8) and attach (8) to (6).
all
bolts.
If the Resistance Lever Arm (8) does not swing freely.
Turn back the nut (BA) till the arm swings freely.
NOTE:
Wrench Tighten
NOTE:
