Configuration
2013-08-14
123
Pos: 74 /806-IHSE/Konfiguration/480_Konsolen-Einstellungen/480-xx/Extender OSD @ 8\mod_1351502028499_6.doc @ 69501 @ 3 @ 1
5.8.3 Extender OSD
In this menu the settings for the Extender OSD can be adjusted. These
are local settings that can be made individually for each console.
You can select between the following Extender OSD settings:
Field Selection Description
activated When executing the key sequence for
opening the OSD, a selection list for
switching CPU devices will be displayed
in the center of the monitor. Pressing the
button <F7> within the selection list
opens the standard OSD. Enable CPU
Selection
deactivated Function not active (default)
activated
Enable Extender OSD (default: YES) Enable
Connection
Info
deactivated Function not active
activated Update connection changes during fade-
in of Extender OSD (default: YES) Update
Connection
Info
deactivated Function not active
Display Time 0-999
seconds Duration of OSD fade-in (default: 10)
Horizontal
Position 10 pixels Horizontal OSD position (default: -2)
Vertical
Position 10 pixels Vertical OSD position (default: 2)
When setting the horizontal OSD position, a prefixed minus describes the
orientation to the right edge of the monitor, e.g. -2 means 2 x 10 = 20
pixels of distance to this edge. When setting a vertical position, a prefixed
minus describes the orientation to the bottom edge of the monitor.
If the function Update Connections is deactivated, the Extender OSD
only appears when switching via OSD.
You have the following possibility to access the menu:
