Status LEDs at I/O boards:
Pos. LED
Status
Description
Light
blue
I/O board in boot process
Red
flashing
I/O board in registration process
Red/
Yellow
flashing
I/O board in Service Mode or firmware
conflict with CPU board
Green
flashing
Operating condition, I/O board
registered at the matrix
1
Status 1
Green
I/O board de-registered (locking pin
pulled out)
White
I/O board in boot process
Blue
I/O board in registration process
Blue
flashing
Operating condition, communication
active with CPU board active
2
Status 2
Red
flashing
I/O board de-registered (locking pin
pulled out)
