6.1.4 Addressing of Main and Sub Matrices
The Draco tera can be cascaded in two steps. You can optionally send the
commands (including opening the OSD) to the main or the sub matrix.
Whenever command mode is activated, you can select by a <m> or a <s>,
if all of the following commands should be handled in the main or in the
sub matrix.
OSD Access
 OSD access to the main matrix:
<Left Shift>, <Left Shift>, <m> (optional), <o>
 OSD access to the sub matrix:
<Left Shift>, <Left Shift>, <s>, <o>
Example: Switching to the CPU port 23 of the sub matrix.
1. Switching to the CPU Port (e.g. 12) of the master matrix that have the
connection to the sub matrix:
<Left Shift>, <Left Shift>, <1>, <2>, <Enter>
2. Switching to the CPU Port 23 of the sub matrix:
<Left Shift>, <Left Shift>, <s>, <2>, <3>, <Enter>
The selected main matrix / sub matrix mode is permanently activated until
the other mode will be manually activated. This means that if you
select <s> for example, all prospective commands will be sent to the
slave, but not if the Command Mode is left in the meantime.
