System-10-N2 BTU Meter Installation and Operation Guide 05/14 - 0655-5 / 18322
Page 13
NPT
1
NPA
2
UNITS POINT DESCRIPTION RANGE/VALUE
BO 2 None Reset (Zero)
Volume Total, ADF-2
OVERRIDE
Binary Output,
Object 2 - ON
BO 5 None Rest (Zero)
Auxiliary Pulse Sum (Di3)
OVERRIDE
Binary Output,
Object 5 - ON
Note 1: Network Point Type Note 2: Network Point Address
2.1.2 Dual or Bi-Directional Mode Point Information
In either dual or bi-directional operation, two registers are available for the accumulation
of energy and two are available for the accumulation of volume. Thus, four ADF points are
required. Four binary output points are required to zero the four ADF energy and volume
accumulation registers.
NPT
1
NPA
2
UNITS POINT DESCRIPTION RANGE / VALUE
AI 1 Selectable
(See Energy Rate Table)
Energy Rate 0 – 999,999
AI 2 Selectable
(See Volume Rate Table)
Volume Rate 0 – 999,999
AI 3 Deg F Supply Temperature 0.0 Deg F – 250.0 Deg F
AI
4
Deg F Return Temperature 0.0 Deg F – 250.0 Deg F
BI
1
None Heating – Cooling Indicator 0 – Heating; 1 - Cooling
ADF 1 Selectable
(See Energy Total Table)
Mode 1 Energy Total 0 – 999,999
ADF 2 Selectable
(See Volume Total Table)
Mode 1 Volume Total 0 – 999,999
ADF 3 Selectable
(See Energy Total Table)
Mode 2 Energy Total 0 – 999,999
ADF 4 Selectable
(See Volume Total Table)
Mode 2 Volume Total 0 – 999,999
ADF 5 User Defined Auxiliary Pulse Input Sum
(Di3)
0 – 999,999
BO 1 None Reset Mode 1 Energy Total OVERRIDE
Binary Output,
Object 1 - ON
BO 2 None Reset Mode 1 Volume Total OVERRIDE
Binary Output,
Object 2 - ON
BO 3 None Reset Mode 2 Energy Total OVERRIDE
Binary Output,
Object 3 - ON
