SPECIFICATIONS
VIDEO SERVER SPECIFICATIONS
Model
NE-VS201
Video Input
1CH BNC
Video Output
1CH BNC loop out
Compression
H.264 / MJPEG
Dual Streaming
H.264 + H.264 / H.264 + MJPEG
Resolution
NTSC: 720 x 480 / PAL: 720 x 576
Frame Rate
NTSC: 30IPS @ D1 / PAL: 25IPS @ D1
Motion Detection
Yes
Audio Inputs
1
Audio Outputs
1
Audio Streaming
Full-duplex, Half-duplex, Simplex
Audio Compression
G.711 / G.726
Alarm Input
1
Alarm Output
1
Network
10/100 Ethernet
Web Connection
IE (ActiveX)
User Accounts
20
User Levels
Administrator or User
Connections
TCP/UDP/IP, HTTP, FTP, SMTP, ARP, ICMP, DHCP, Telnet,
RTP/RTSP
PTZ Control
RS-485
PTZ Protocols
Pelco D, Pelco P, Optix III, Optix I
Operational Temp
14°F ~ 122°F (-10°C ~ 50°C)
Active/Passive Cooling
Passive Cooling
Power Consumption
4.2W
Rated Amperage
< 350mA
Input Voltage
12vDC / PoE
Weight
0.44 lbs (0.2kg)
Dimensions
L: 5.39" (137mm) x W: 3.9" (99mm) H: 1.1" (28mm)
Housing
White / Blue
Voltage Out
12vDC
Power Out
6W
Max Current
500mA
