32
GREASING
A properly maintained lubrication schedule will provide a smooth running
machine for many years. All pivot locations have grease fittings. The following
information shows and describes where all lubrication points are located. Use a
quality EP2 bearing grease (WITH NO MOLYBDENUM COMPOUNDS) or
equivalent
.
DECKS P.T.O. SHAFTS FRAME

Spindles* (See Below)

3 Pivots per Wing
Deck*

7 Pivots on Rear Deck*
*As Required

See TDR-22 P.T.O.
shafts below

8 Pivot Locations*

2 Wheels*
*As Required
CHECK FOR PROPER OIL LEVEL IN GEAR BOXES DAILY
GREASING SCHEDULE & LOCATION
P.T.O. SHAFTS
Your TDR-22 mower is equipped with reduced maintenance drive shafts. This
means that greasing of the shafts must be done only every 100 hours of use, or 8 to
10 days of use. This applies to the main input, intermediate and deck shafts supplied
with this mower. These shafts are also equipped with the EASY LOCK GUARD
SYSTEM.
BLADE SPINDLE GREASING
This TDR-22 mower is equipped with fully sealed roller bearings that require no
regular maintenance. A predetermined amount of grease has been placed in both the
top and bottom bearings in order to provide adequate lubrication throughout the life
of the bearing.
