t
O
separate
a
pk
kiln
intO
sectiOns
s
tep
1
Refer to page 37, Removing the Lid Lifter, for instructions on Lid Lifter assembly.
●
s
tep
3
Remove the screws from the side of the red control box and swing the panel to the side.
●
s
tep
4
Number the feeder wires using tape so you can remember where they will be reconnected.
●
s
tep
5
Loosen the terminal block lugs that hold the feeder wires. These are located on the fiberglass lined
●
heat baffle. Remove wires from the three terminal blocks.
s
tep
6
Slide the thermocouple connectors off the terminal strip.
●
Lift the red control box up to remove it.
●
s
tep
7
Unhook the draw pull catches and lift the sections using the handles provided.
●
t
O
reasseMBle
pk
kilns
s
tep
1
Stack the sections in original sequence.
●
s
tep
2
Place the switch box on its hinges.
●
s
tep
3
Reattach the feeder wires in their original positions.
●
Make sure the connection is very tight to avoid
electrical problems.
s
tep
4
Reattach the thermocouple wires in their original position, positive to positive and negative to
●
negative.
s
tep
5
Reattach the screws which secure the control box to the kiln jacket.
●
